Weld on Anodes ATS-1 Aluminum
Type: Hull Anodes
Vendor: Sea Shield Marine
Description:
- ATS-1 with two 1/2″ slotted holes on 7-7/8″ centers.
- Galvanized steel straps for weld-on installation.
- ATS can be ordered with aluminum straps.
| Part No |
WT (lb) | Thickness | Width | Length | Steel Strap Size |
|---|---|---|---|---|---|
| ATS-1 | 1.8 | 1-1/2″ | 3″ | 5-7/8″ | 1/8″ x 3/4″ x 10″ |
All of our Weld-on anodes are precision manufactured using the highest grade metals and conform to Mi-Spec standards (Mil-A-18001 Zinc & Mil-A-24779 Aluminum). We’ve taken special care to makes sure that versatility exits throughout the majority of our weld-on anode line: All anodes are available with standard galvanized steel straps for weld-on installation. Certain anode units can be ordered with aluminum or bronze weld-on straps upon request. Custom galvanized steel straps on select models also allow for bolt-on installation. Please contact us for inquiries
